M500 thermal sight night vision hunting camera module with ULIS sensor
1. No shutting non-uniformity calibrating technology
2. Super lower power consumption: <1.2W
3. Instantaneous boot: <4S
4. Low working voltage: 2.5V-5.5V
5. Small size and light weight
6. High performance of temperature impact and environmental adapability
Technical parameters of M500 thermal imaging module
Items | Core | M500 |
Detector characteristic | Detector | Uncooled amorphous silicon FPA |
Array format/Pixel pitch | 640×480 / 17um | |
Sensitivity | ≤60mk at f/1.0 300K | |
Frame rate | 50Hz | |
Spectral range | 8~14um | |
Imaging process | Shutter calibration | No shutter technology |
Booting time | <4s | |
Noise reduction | Digital filter | |
Image resolution | 640×480 | |
Lens option | 12mm,19mm,25mm,35mm,40mm,50mm,75mm,100mm | |
Thermal imaging adjustment | Polarity | White hot /Black hot |
Mirror image | Horizontal/Vertical | |
Zoom | ×2,×4 | |
Manual Gain | Cycle adjustment | |
Auto Gain | Auto adjustment | |
Power | Working voltage range | DC: +2.5V~+5.5V |
Typical voltage | DC:3.6V | |
Power consumption | <1.2W | |
Anti reverse voltage | Yes | |
Anti over voltage | Yes | |
Environmental parameters | Working temperature | -20ºC~+60ºC |
Optional:-40ºC~+60ºC | ||
Storage temperature | -45ºC~+65ºC | |
Humidity | 5%~95% Non condensing | |
Vibration and shock | Vibration:GJB 150-16 2.3.1 | |
Axial:GJB 150-18 Test7 100g/6ms | ||
Anti temperature impact | -5ºC/min(-40ºC~+60ºC) | |
Physical parameters | Weight | <40g |
Dimension | 42.5mm×41mm×20mm | |
Interface | Power input port | Yes |
Serial port | RS-232 | |
Analog video output | BNC(75Ω);Support dual video output | |
Digital video output | 14Bit(50Hz) | |
Keyboard | 4 buttons keyboard |
Lens Details :
M500 thermal sight camera/night sight thermal camera/night vision thermal camera
Analog video output :
